The Construction Set

Digital PDF

Delivery: Immediate Digital Download (PDF), printable at full architectural scale.

The Full Construction Set contains the complete architectural drawings required for permitting and construction of the home. Drawings are prepared at 1/4" scale and organized to provide builders and contractors with clear guidance throughout the building process.(note: additional information may be required depending on state/ local permitting guidelines)

The Construction Set includes:

Floor Plans
Lower and  Main Level Floor Plans prepared at 1/4" scale, including room layouts, wall dimensions.

Roof Plan
A detailed 1/4" scale roof plan showing roof form, ridges, valleys, and slopes.

Exterior Elevations
All sides of the home illustrated at 1/4" scale, showing architectural detailing, materials, and proportions.

Building Sections & Exterior Details
Key 1/4" scale building sections and exterior construction details

Electrical Plan
N/A

Foundation Options

Depending on site conditions and homeowner preference, the following foundation plans are available for this design:

• Slab Foundation Plan only

All foundation plans are prepared at 1/4" scale.
